| PROZESSOR |
|
| Chipset |
ARM-based CC2640R2F by Texas Instruments |
| Memory |
275 kB flash, 28 kB RAM |
| CONNECTIONS |
|
| Bluetooth / Frequency / Power |
Low Energy Technology / 2,4 GHz / −21 dBm / +5 dBm (adjustable in 13 steps) |
| Integration |
via BLE gateway, optional via Android & iOS SDK |
| FUNCTIONS |
|
| Protocol |
iBeacon, safectory asset tag position |
| Dataset |
iBeacon (major, minor, UUID), scanned location beacons (IPS/RTLS), battery status |
| Buzzer |
for audio alarm |
| Acceleration sensor |
for smart activation and other functions (IPS/RTLS) |
| Configurations |
standard tag, standard beacon, monitored beacon, individual |
| CASING |
|
| Material / Color |
ABS white |
| Mounting |
Mounting interface |
| Protection / Size / Weight |
IP 44, UL 94 V-0, flame resistant, CE admission / 43 × 43 × 19 mm / 22 g |
| ELEKTRISCHE SPEZIFIKATIONEN |
|
| Connection |
2 colored cables, DC 4.75V – 36V, approx. 65mm long, tinned contacts |
| Input Voltage [VDC] Nominal (Range) |
4,5 to 36 VDC |
| Power consumption |
0.2 mA TYP, 1.5mA MAX |
| Further properties |
Not reverse polarity protected |
| ENVIRONTMENTAL |
|
| Temperature / Humidity |
−30 °C up to +60 °C / from 0 % up to 100 % |
| ADMISSION |
|
| CE-admission |
https://safectory.com/beacon-ce-admission |
